Dupont UF Membranes IntegraTec™ XP 51 IG For System Designs With Limited Height Or Space

Detalhes do produto:

Lugar de origem:	China
Marca:	Dupont
Certificação:	CE
Número do modelo:	Integratec ™ XP 51 IG (anteriormente SFP-2860XP)
Documento:	UF-IntegraTec-XP51-IG-en.pdf

Condições de Pagamento e Envio:

Quantidade de ordem mínima:	1 unidade
Preço:	Negociável
Detalhes da embalagem:	Embalagem padrão de exportação
Tempo de entrega:	5-8 dias de trabalho
Termos de pagamento:	T/T
Habilidade da fonte:	60000 unidades por mês

Contato

Todos os Produtos

caixa de distribuição da iluminação (43)

caixa de distribuição elétrica (33)

Caixa de distribuição à prova de intempéries (48)

Caixa do cerco da fibra de vidro (60)

Interruptor automático de transferência do ATS (68)

Módulos EDI (160)

Módulos de membrana de ultrafiltração (76)

interruptor industrial (85)

sistema solar do picovolt (72)

Estação de carregamento elétrica de EV (21)

Relés modulares do sincronismo (12)

Relés de controle da automatização (64)

Transformador do regulador de tensão (16)

Balões da iluminação do filme (144)

Luz do balão da lua (145)

Balões do diodo emissor de luz do tripé (122)

Torre clara inflável (76)

Acessórios do bloco de terminais (6)

Descrição de produto detalhada

Modo de filtragem XP 51 IG:	Pressurizado externo	Tipo de membrana XP 51 IG:	Fibra oca
XP 51 IG Material de membrana:	PVDF (Fluoreto de Polivinilideno）	XP 51 Tamanho do poro da membrana Ig:	Aprox. 0,03 µm
Processo de operação do módulo:	Sem saída	Área de membrana ativa Ig 51 Ig:	51 m²

DuPont XP 51 IG Ultrafiltration Membrane: High-Flux Industrial Water Filtration System
The DuPont XP 51 IG ultrafiltration membrane is designed for advanced separation in industrial water treatment. With its high-flux characteristics, this membrane achieves outstanding filtration performance while maintaining a precise molecular weight cut-off that effectively removes particles, bacteria, and macromolecules. Built to withstand demanding industrial conditions, it offers strong chemical resistance and a long operational life. The membrane's optimized configuration supports stable operation with low energy demand, making it well-suited for reverse osmosis pretreatment, wastewater reuse, and process water purification across a range of industrial sectors.

Product Specifications

Attribute	Value
Brand	Dupont™
Model	XP 51 IG
Filtration Type	Out-In Pressurized
Membrane Type	Hollow fiber
Membrane Material	PVDF (Polyvinylidene Fluoride)
Membrane Pore Size	Approx. 0.03 µm
Module Operating Process	Dead-end
Other Wetted Components	Polyurethane, polyethylene, and polyamide
Active Membrane Area	51 m²
Shipping Weight	60 kg
Weight Empty	48 kg
Weight Filled	83 kg
Primary Application	Wastewater treatment

Key Advantages

Municipal drinking water treatment
Industrial utility water processing
Industrial wastewater reuse
Municipal wastewater filtration
RO pretreatment solutions

Product Description

The DuPont IntegraTec XP 51 IG is an advanced ion exchange membrane engineered for high-efficiency chlor-alkali electrolysis, delivering superior performance in caustic soda (NaOH), chlorine (Cl₂), and hydrogen (H₂) production.

Designed with DuPont's proprietary IntegraTec technology, this membrane ensures exceptional current efficiency (≥96%) and low energy consumption, optimizing operational costs in membrane cell electrolyzers. Its reinforced perfluorinated polymer structure provides outstanding resistance to harsh chemical environments, including concentrated brine and high-temperature conditions.

The XP 51 IG features low gas permeability and stable voltage drop, ensuring consistent output and extended service life (typically >5 years). Ideal for modern electrolysis plants, it supports sustainable production with reduced power requirements and minimized caustic impurities.

Why Choose the XP 51 IG?

Smarter Filtration, Unmatched Purity

Proprietary pore structure technology ensures superior removal of pathogens, microplastics, and colloidal particles while preserving vital minerals for safer, cleaner water outcomes.

Ultra-High Efficiency

Engineered with DuPont's cutting-edge hydrophilic polymers, the XP 51 IG achieves up to 20% higher flux rates compared to conventional membranes, translating to faster processing and energy savings.

Built for Tough Conditions

Exceptional resistance to chlorine, pH extremes, and organic fouling ensures reliable operation in industrial wastewater, brackish water, or high-turbidity applications.

Sustainable by Design

Reduced fouling tendencies and easy-to-clean surfaces minimize chemical usage and downtime, supporting eco-conscious operations and lower lifecycle costs.

Plug-and-Play Compatibility

Seamlessly integrates into modular filtration systems, offering scalable solutions for both retrofits and new installations.
